V-LINE

SPECIFICATIONS

• -------- GENERAL DATA --------
• Signal Type

  Analog
• Copper Type

  OFC Oxygen Free Copper
• Application Type

  Speaker Cable
• Application Area

  Installation
• Color

  Red/Black
• -------- TECHNICAL DATA --------
• Conductor Core

  2
• Conductor mm2

  2.5
• Conductor AWG

  13
• Insulation Material

  75P PVC
• Insulation Color

  Red/Black
• Insulation Ø mm

  3.5mm
• -------- ELECTRICAL DATA --------
• Capacitance Conductor/Conductor Per Km

  <145.3PF
• Conductor Resistance Per 1 km

  6.88Ω
