V-LINE

SPECIFICATIONS

• -------- GENERAL DATA --------
• Signal Type

  Analog
• Copper Type

  OFC Oxygen Free Copper
• Application Type

  Speaker Cable
• Application Area

  Touring/Installation
• Color

  Black
• -------- TECHNICAL DATA --------
• Conductor Core

  4
• Conductor mm2

  4.0
• Conductor AWG

  11
• Insulation Material

  75P PVC
• Insulation Color

  Red/Black/White/Yellow
• Insulation Ø mm

  4.2mm
• Jacket Material

  Environmental PVC
• Jacket Ø mm

  14.3mm
• -------- ELECTRICAL DATA --------
• Capacitance Conductor/Conductor Per Km

  <236.7PF
• Conductor Resistance Per 1 km

  4.3Ω
